Product Application Area
Remote control garage door Remote control house door Remote control Lamp Remote control car led Remote control Gate and other remote control device.
Features
1:Mini Size and Multi-function control:
Only 30mm*30mm in size, it can be put into 95% of the devices on the market;
 A variety of control methods to meet your different needs and make your life more intelligent and convenient.
2:Easy to Install:
Input:V+ V- ;Output : No . Nc .COM
Standard 86 back box installation method, no special tools or skills required, easy installation, making your life more convenient.
3:water proof IP68:
Due to its strong waterproof and dustproof performance, the waterproof IP68 remote control has a longer service life. This means you don't need to replace your remote control as frequently, saving maintenance costs and time.
4:Time Controlled and Stable and Reliable:
You can set a specific time on the wireless remote control switch to allow the appliance to automatically turn on or off at the specified time. Not only does this save you time, it also ensures that the use of appliances is more planned and efficient.
 High-performance relays ensure the stability and reliability of the product, making your life more secure.
Easy to use mode :
Remote mode 2: Toggle Mode
Remote mode 3: Latched Mode
Remote mode 4: Time Delay  Mode
Press and hold "A", relay will turn on;Release A button, this relay will turn off after
5 seconds(10/15 seconds ).
Setting the Signal :
Remote mode 1: Momentary Mode
Press learning button 1 time,press A button once,then press B button once
Remote mode 2: Toggle Mode
Press learning button 2 times,press A button once.
Remote mode 3: Latched Mode
Press learning button 3 times,press A button once,then press B button once.
Remote mode 3: Time Delay  Mode
Press learning button 4 times(or 5/6 times),press A button once.
Clear the Signal :
Only Press learning button once 8 times.
Working voltage : DC 5V – 30V
Input vlotage  : 1~250V
Output vlotage  : 1~250V
Quiescent Current  : <5MA
Max current  : 10A
Max load : 2200W
RF frequency  : 433MHz
Working temperature  : -30~+80
Receiving Sensitivity  : >97dbm
Amount of storage remote controls  : 25 pieces
Support encoding  : 1527 Leaning code /2262 fixed code
RF Operating mode  : ASK superheterodyne wireless reception
Receiving range  : Open space is more than 50 meters
Remote operating mode : Momentary Mode / Toggle Mode /Latched Mode  / Delay Mode
RF frequency : 433MHz
Support encoding : 1527 Leaning codeÂ
Transmitting range : Open space is more than 50 meters
Battery  :  2pcs * CR2016 ( include )
Two wiring methodsÂ
