1
|
Model/Feture
|
CSPY-S3-DC
|
|
2
|
Material
|
Copper turbine
|
|
3
|
IP Rating
|
IP57，Fully sealed waterproof motor, equipped with waterproof ventilation valve head
|
|
4
|
Leaf max weight (KG)
|
500kg
|
|
5
|
Leaf max leghth (m)
|
6m
|
|
6
|
Rated Absorbed power (w)
|
80W
|
|
7
|
Working Frequency
|
90%
|
|
8
|
Power Supply(V)
|
DC12V,7.5A
|
|
9
|
DC24V,3.5A
|
|
|
10
|
Limit switch
|
magnetic limit
|
|
11
|
Limit switch quantity
|
2,Open door limit and close door limit
|
|
12
|
Teeth gear
|
16 Teeth gear，Larger volume
|
|
13
|
Motor Speed
|
1800RPM/MIN
|
|
14
|
Push force (N)
|
700N
|
|
15
|
Max linear load free speed(m/sec)
|
16-18m/Min
|
|
16
|
Built in battery
|
12V-1pc12V.7/9ah or batteries in series (option)
|
|
17
|
24V-2pcs 12V.7/9ah batteries in series (option)
|
|
|
18
|
External battery
|
12V: One or more 12v7 / 9ah batteries in parallel
|
|
19
|
24V:Two 12V, 7/9ah batteries in series
|
|
|
20
|
Remote control
|
30-50meters,433.92 MHz
|
|
21
|
Recovery temperature(℃)
|
-20℃-50℃
|
|
22
|
Gross weight
|
15KG
|
